Expandable Eps Raw Material Granules


Product Detail

FAQ

Product Tags

Products Introduction

Expanded Polystyrene (EPS) is a light polymer. It is a foamed plastic which is added with a foaming agent by using a polystyrene resin and softened at the same time to generate a gas to form a hard closed cell structure. The uniformly closed cavity structure makes the EPS have small water absorption and good heat preservation. light weight and high mechanical strength Products made from foamed polystyrene are nearly ubiquitous, for example packing materials, insulation, and foam drink cups.

Eps Raw Material  (4)

Classification

Eps Raw Material

Technical Data

High Expansion Grade

Specification P301 P302 P303 P401 P501
 Beads Size mm 1.00-1.60 0.85-1.25 0.70-0.90 0.50-0.80 0.40-0.60
 Vol.Cont % 7.81 7.66 7.39 7.09 6.82
 H2O % 0.45 0.57 0.38 0.51 0.37
 Avg.size mm 1.25 1.01 0.81 0.63 0.53
 Sieving ≥ 95% 98 100 100 100 99.8
 Result(g/l) 12.5 13.5 14.33 18.67 20.2
 Density Max(I) 11 13.11 14.5 18.67 20.2
(g/l)
 Range Mix(I) 12.5 14.28 17.67 20 25
  (g/l)

Standard Grade

Specification
F301
F302
F303
F401
Beads Size mm
1.00-1.60
0.85-1.25
0.70-0.90
0.50-0.80
Vol.Cont %
6.85
6.8
6.66
6.27
H2O %
0.95
1.12
1.25
1.26
F.M %
≤0.10
≤0.10
≤0.10
≤0.10
Avg. size mm
1.32
1.01
0.8
0.63
PRE-EXPENSION DENSITY
12.0~14.0
14.0~16.0
15.0~18.0
18.0~25.0
Sieving ≥95%
95
95
95
95
Result (g/l)
13.67
15.18
17
23.22
DENSITY

Max(I) (g/l)
12.58
14.58
16.67
19

RANGE
Min(I) (g/l)
14
16
18
24.33
Oxygen Index
≥30
≥30
≥30
≥30


Application

Eps Raw Material-7

Packing Box

eps raw material3
eps raw material4
